NB-IoT / eMTC / EDGE / GPRS / GNSS HAT for Raspberry Pi Based on SIM7000E

Beschreibung

• Raspberry Pi connectivity, compatible with Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+; Supports TCP, UDP, PPP, HTTP, FTP, MQTT, SMS, Mail, etc;Supports GNSS positioning (GPS,GLONASS,BeiDou and Galileo)

• Onboard USB interface, to test AT Commands, get GPS positioning data, and so on; Breakout UART control pins, to connect with host boards like Arduino/STM32

• Onboard voltage translator, 3.3V by default, allows to be switched to 5V via 0Ω resistor; SIM card slot, compatible with both normal SIM card and NB-IoT specific card

• 2x LED indicators, easy to monitor the working status; Baudrate: 300bps~3686400bps; Control via AT commands (3GPP TS 27.007, 27.005, and SIMCOM enhanced AT Commands)

• Supports SIM application toolkit: SAT Class 3, GSM 11.14 Release 98, USAT;Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32)

• Größe:SIM7000E NB-IoT HAT

Description:

• This Raspberry Pi HAT features multi communication functionalities: NB-IoT, eMTC, EDGE, GPRS, and GNSS.

• The NB-IoT (NarrowBand-Internet of Things) and eMTC (enhanced Machine Type Communication) are rising IoT communication technologies evolved from LTE (4G),with advantages include low power, )

• low cost, wide coverage, etc. They are suited for applications such as intelligent instruments, remote controlling, asset tracking, remote monitoring, E-health, mobile POS terminals, sharing bikes, )

• and so on. While the GSM/GPRS, and EDGE are traditional 2G/2.5G technologies capable of sending SMS or making other wireless communications.)

• Therefore, the SIM7000E NB-IoT HAT would be an ideal choice for either evaluating new rising technologies, or simply communicating/positioning via multiple ways.

Features

• Raspberry Pi connectivity, compatible with Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+

• Supports TCP, UDP, PPP, HTTP, FTP, MQTT, SMS, Mail, etc.

• Supports GNSS positioning (GPS,GLONASS,BeiDou and Galileo)

• Onboard USB interface, to test AT Commands, get GPS positioning data, and so on

• Breakout UART control pins, to connect with host boards like Arduino/STM32

• Onboard voltage translator, 3.3V by default, allows to be switched to 5V via 0Ω resistor

• SIM card slot, compatible with both normal SIM card and NB-IoT specific card

• 2x LED indicators, easy to monitor the working status

• Baudrate: 300bps~3686400bps

• Control via AT commands (3GPP TS 27.007, 27.005, and SIMCOM enhanced AT Commands)

• Supports SIM application toolkit: SAT Class 3, GSM 11.14 Release 98, USA

Package including:

• Note: the Raspberry Pi in the photo is NOT included.

• SIM7000E NB-IoT HAT x1

• GSM Antenna x1

• GPS External Antenna (B) x1

• USB type A plug to micro plug cable x1

• RPi screws pack (2pcs) x1
